LinkedIn ALTAIR 2S
Product code:ALT59818
Type:LED-1L35E700US21/421 4K#
Model
Other products
Technical
| Types of luminaires: | Classic on/off |
| Mounting type: | surface mounted |
| Base material: | steel |
| Shade material: | three-layer glass TRIPLEX OPAL |
| Base color: | white Ral9003 |
| Shade color: | white |
| Holding the shade: | folding system |
| Mounting location: | ceiling/wall |
| Width: | 390 mm |
| Length: | 362 mm |
| Height: | 128 mm |
| mounting holes (diameter): | 4xØ5mm |
| Installation wire (diameter): | 2xØ16mm |
| Energy class: | D |
| Impact strength: | IK01 |
Electric
| Number of power supplies: | 1 |
| Power of one supply: | 19 W |
| Output: | 19 W |
| Ingress Protection: | IP41 |
| Socket: | LED modul |
| terminal block: | snap terminal block |
Luminous
| Lum. flux of luminaire: | 2450 lm |
| Lum. flux of light source: | 3220 lm |
| Temperature: | 4000 K |
| Rated life time LED L80/B10: | 50000 |
| CRI: | Ra80 |
| MacAdam: | 3 |
Logistic
| EAN | 8591728063429 |
| Weight NTTO | 4.7 Kg |
| Weight BTTO | 5 Kg |
| Number of cartons | 1 |
| Package volume | 0.018 m3 |
| Package 1 width | 0.365 m |
| Package 1 length | 0.365 m |
| Package 1 height | 0.135 m |
| Warranty: | 60 |
230V
IP41
