ALKOR D2
Short description of the luminaire
Cylindrical ceiling or wall light with shade diameter Ø140 mm. Product consists of decorative metal base and handmade three-layer opal glass shade TRIPLEX OPAL with matt surface. Shade is fixed by two-step clamp holders. Suitable for indoor and outdoor use.
230V
IP44
Lamps
Classic on/off
| Code | Type | Base color | Ingress Protection | Socket | CCT (K) | Input [W] | Lum. flux of light source [lm] | Lum. flux of luminaire [lm] | Warranty (month) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| ALK67605 | LED-5L05E600KN02P/406 NB 4K# |
|
IP44 | LED modul | 4000 | 10 | 1520 | 1220 | 60 | Detail | |
| ALK67604 | LED-5L05E600KN02P/406 NL 4K# |
|
IP44 | LED modul | 4000 | 10 | 1520 | 1220 | 60 | Detail | |
| ALK67603 | LED-5L05E600KN02P/406 MS 4K# |
|
IP44 | LED modul | 4000 | 10 | 1520 | 1220 | 60 | Detail | |
| ALK67602 | LED-5L05E600KN02P/406 C 4K# |
|
IP44 | LED modul | 4000 | 10 | 1520 | 1220 | 60 | Detail | |
| ALK67601 | LED-5L05E600KN02P/406 B 4K# |
|
IP44 | LED modul | 4000 | 10 | 1520 | 1220 | 60 | Detail | |
| ALK67105 | LED-5L05E600KN02P/406 NB 3K# |
|
IP44 | LED modul | 3000 | 10 | 1460 | 1170 | 60 | Detail | |
| ALK67104 | LED-5L05E600KN02P/406 NL 3K# |
|
IP44 | LED modul | 3000 | 10 | 1460 | 1170 | 60 | Detail | |
| ALK67103 | LED-5L05E600KN02P/406 MS 3K# |
|
IP44 | LED modul | 3000 | 10 | 1460 | 1170 | 60 | Detail | |
| ALK67102 | LED-5L05E600KN02P/406 C 3K# |
|
IP44 | LED modul | 3000 | 10 | 1460 | 1170 | 60 | Detail | |
| ALK67101 | LED-5L05E600KN02P/406 B 3K# |
|
IP44 | LED modul | 3000 | 10 | 1460 | 1170 | 60 | Detail | |
| ALK52168 | IN-12KN02P/406 NB* |
|
IP44 | E27 | 25 | 60 | Detail | ||||
| ALK52167 | IN-12KN02P/406 NL* |
|
IP44 | E27 | 25 | 60 | Detail | ||||
| ALK52166 | IN-12KN02P/406 MS* |
|
IP44 | E27 | 25 | 60 | Detail | ||||
| ALK52165 | IN-12KN02P/406 C* |
|
IP44 | E27 | 25 | 60 | Detail | ||||
| ALK52164 | IN-12KN02P/406 B* |
|
IP44 | E27 | 25 | 60 | Detail |
