CARINA LE1

Short description of the luminaire

Round pendant light with shade diameter Ø375 mm. Product consists of cableless pendant LE and handmade three-layer opal glass shade TRIPLEX OPAL with matt surface. Shade is fixed by two-step clamp holders. Suitable for indoor use.

Shade material:
Base color:

Category (series):
Types of luminaires:
Mounting type:
Base material:
Shade color:
Mounting location:
Width:
Length:
Height:
Hinge lengths:
Energy class:	D
Impact strength:	IK01
Output:	24 25
IP:
Sensor:	Yes No
Battery type:
Emergency time:
Lum. flux of luminaire:	2090 2480
Lum. flux of light source:	3320 3930
Temperature:

Show advanced filter

Reset

230V

IP40

Possibility of design with dimmable DALI ballast

Possibility of design with Bluetooth wireless control

Lamps

Classic on/off Dimmable

Code	Type	Ingress Protection	Socket	CCT (K)	Input [W]	Lum. flux of light source [lm]	Lum. flux of luminaire [lm]	Délka závěsu (mm)	Warranty (month)
CAR66874	LED-1L17E700ZLEN76/425/L100 S 4K#	IP40	LED modul	4000	25	3930	2480	1000	60	Detail
CAR66872	LED-1L17E700ZLEN76/425/L100 C 4K#	IP40	LED modul	4000	25	3930	2480	1000	60	Detail
CAR66870	LED-1L17E700ZLEN76/425/L100 B 4K#	IP40	LED modul	4000	25	3930	2480	1000	60	Detail
CAR66374	LED-1L17E700ZLEN76/425/L100 S 3K#	IP40	LED modul	3000	25	3770	2380	1000	60	Detail
CAR66372	LED-1L17E700ZLEN76/425/L100 C 3K#	IP40	LED modul	3000	25	3770	2380	1000	60	Detail
CAR66370	LED-1L17E700ZLEN76/425/L100 B 3K#	IP40	LED modul	3000	25	3770	2380	1000	60	Detail
66370	LED-1L17C07ZLE11/425/L100 B 3000#	IP40	LED modul	3000	24	3320	2090	1000	60	Detail
66372	LED-1L17C07ZLE11/425/L100 C 3000#	IP40	LED modul	3000	24	3320	2090	1000	60	Detail
66374	LED-1L17C07ZLE11/425/L100 S 3000#	IP40	LED modul	3000	24	3320	2090	1000	60	Detail
66870	LED-1L17C07ZLE11/425/L100 B 4000#	IP40	LED modul	4000	24	3500	2210	1000	60	Detail
66872	LED-1L17C07ZLE11/425/L100 C 4000#	IP40	LED modul	4000	24	3500	2210	1000	60	Detail
66874	LED-1L17C07ZLE11/425/L100 S 4000#	IP40	LED modul	4000	24	3500	2210	1000	60	Detail

Code	Type	Ingress Protection	Socket	CCT (K)	Input [W]	Lum. flux of light source [lm]	Lum. flux of luminaire [lm]	Délka závěsu (mm)	Warranty (month)
CAR66875	LED-1L17E700ZLEN76/425/L100 S DALI 4K#	IP40	LED modul	4000	25	3930	2480	1000	60	Detail
CAR66873	LED-1L17E700ZLEN76/425/L100 C DALI 4K#	IP40	LED modul	4000	25	3930	2480	1000	60	Detail
CAR66871	LED-1L17E700ZLEN76/425/L100 B DALI 4K#	IP40	LED modul	4000	25	3930	2480	1000	60	Detail
CAR66375	LED-1L17E700ZLEN76/425/L100 S DALI 3K#	IP40	LED modul	3000	25	3770	2380	1000	60	Detail
CAR66373	LED-1L17E700ZLEN76/425/L100 C DALI 3K#	IP40	LED modul	3000	25	3770	2380	1000	60	Detail
CAR66371	LED-1L17E700ZLEN76/425/L100 B DALI 3K#	IP40	LED modul	3000	25	3770	2380	1000	60	Detail
66371	LED-1L17C07ZLE11/425/L100 B DALI 3000#	IP40	LED modul	3000	24	3320	2090	1000	60	Detail
66373	LED-1L17C07ZLE11/425/L100 C DALI 3000#	IP40	LED modul	3000	24	3320	2090	1000	60	Detail
66375	LED-1L17C07ZLE11/425/L100 S DALI 3000#	IP40	LED modul	3000	24	3320	2090	1000	60	Detail
66871	LED-1L17C07ZLE11/425/L100 B DALI 4000#	IP40	LED modul	4000	24	3500	2210	1000	60	Detail
66873	LED-1L17C07ZLE11/425/L100 C DALI 4000#	IP40	LED modul	4000	24	3500	2210	1000	60	Detail
66875	LED-1L17C07ZLE11/425/L100 S DALI 4000#	IP40	LED modul	4000	24	3500	2210	1000	60	Detail
