MIRA

Short description of the luminaire

Spherical ceiling light with shade size 350×340 mm. Product consists of powder-coated metal base and handmade three-layer opal glass shade TRIPLEX OPAL with matt surface. Shade is fixed by screws. Suitable for indoor use.

Shade material:
Base color:

Category (series):
Types of luminaires:
Mounting type:
Base material:
Shade color:
Mounting location:
Width:
Length:
Height:
Hinge lengths:
Energy class:	D
Impact strength:	IK01
Output:	27 150
IP:
Sensor:	Yes No
Battery type:
Emergency time:
Lum. flux of luminaire:	3430 3620
Lum. flux of light source:	3900 4110
Temperature:

Show advanced filter

Reset

230V

Suitable for mounting on flammable substrates (F)

IP41

Possibility of design with dimmable DALI ballast

Possibility of design with Bluetooth wireless control

Lamps

Classic on/off Sensor Dimmable

Code	Type	Ingress Protection	Socket	CCT (K)	Input [W]	Lum. flux of light source [lm]	Lum. flux of luminaire [lm]	m (Kg)	Warranty (month)
59473	LED-5L06C06S6/195/S12 3000#	IP41	LED modul	3000	27	3900	3430	4,9	60	Detail
59973	LED-5L06C06S6/195/S12 4000#	IP41	LED modul	4000	27	4110	3620	4,9	60	Detail
59476	LED-5L06C06S6/195/S13 3000#	IP41	LED modul	3000	27	3900	3430	4,9	60	Detail
59976	LED-5L06C06S6/195/S13 4000#	IP41	LED modul	4000	27	4110	3620	4,9	60	Detail
59304	LED-5L06C06S6/195/S4 3000#	IP41	LED modul	3000	27	3900	3430	4,9	60	Detail
59804	LED-5L06C06S6/195/S4 4000#	IP41	LED modul	4000	27	4110	3620	4,9	60	Detail
59470	LED-5L06C06S6/195/S14 3000#	IP41	LED modul	3000	27	3900	3430	4,9	60	Detail
59970	LED-5L06C06S6/195/S14 4000#	IP41	LED modul	4000	27	4110	3620	4,9	60	Detail
42430	IN-12S6/195/S4*	IP41	E27		150			4,7	60	Detail
42434	IN-12S6/195/S14*	IP41	E27		150			4,7	60	Detail
42438	IN-12S6/195/S12*	IP41	E27		150			4,7	60	Detail
42442	IN-12S6/195/S13*	IP41	E27		150			4,7	60	Detail

Code	Type	Ingress Protection	Socket	Input [W]	m (Kg)	Warranty (month)
46183	IN-12S6/195/S4 HF*	IP41	E27	75	4,8	60	Detail
46184	IN-12S6/195/S14 HF*	IP41	E27	75	4,7	60	Detail
46185	IN-12S6/195/S12 HF*	IP41	E27	75	4,7	60	Detail
46186	IN-12S6/195/S13 HF*	IP41	E27	75	4,7	60	Detail

Code	Type	Ingress Protection	Socket	CCT (K)	Input [W]	Lum. flux of light source [lm]	Lum. flux of luminaire [lm]	m (Kg)	Warranty (month)
59972	LED-5L06C06S6/195/S14 DALI 4000#	IP41	LED modul	4000	27	4110	3620	4,9	60	Detail
59475	LED-5L06C06S6/195/S12 DALI 3000#	IP41	LED modul	3000	27	3900	3430	4,9	60	Detail
59975	LED-5L06C06S6/195/S12 DALI 4000#	IP41	LED modul	4000	27	4110	3620	4,9	60	Detail
59478	LED-5L06C06S6/195/S13 DALI 3000#	IP41	LED modul	3000	27	3900	3430	4,9	60	Detail
59978	LED-5L06C06S6/195/S13 DALI 4000#	IP41	LED modul	4000	27	4110	3620	4,9	60	Detail
59306	LED-5L06C06S6/195/S4 DALI 3000#	IP41	LED modul	3000	27	3900	3430	4,9	60	Detail
59806	LED-5L06C06S6/195/S4 DALI 4000#	IP41	LED modul	4000	27	4110	3620	4,9	60	Detail
59472	LED-5L06C06S6/195/S14 DALI 3000#	IP41	LED modul	3000	27	3900	3430	4,9	60	Detail
