DELIA LEC2

Short description of the luminaire

Cylindrical pendant light with shade diameter Ø400 mm. Product consists of cableless pendant LE and opal polycarbonate or PMMA shade with decorative black stripe. Shade is fixed by two-step clamp holders. Suitable for indoor use.

Shade material:
Base color:

Category (series):
Types of luminaires:
Mounting type:
Base material:
Shade color:
Mounting location:
Width:
Length:
Height:
Hinge lengths:
Energy class:	D
Impact strength:	IK04 IK10
Output:	24 34
IP:
Sensor:	Yes No
Battery type:
Emergency time:
Lum. flux of luminaire:	2030 2900
Lum. flux of light source:	3690 5270
Temperature:

Show advanced filter

Reset

230V

IP40

Possibility of design with dimmable DALI ballast

Possibility of design with Bluetooth wireless control

Lamps

Classic on/off Dimmable

Code	Type	Ingress Protection	Socket	CCT (K)	Input [W]	Lum. flux of light source [lm]	Lum. flux of luminaire [lm]	Délka závěsu (mm)	Warranty (month)
DEL69910	LED-1L16E700ZLEN83/PM23C/L100 4K#	IP40	LED modul	4000	34	5270	2900	1000	60	Detail
DEL69908	LED-1L16E500ZLEN83/PM23C/L100 4K#	IP40	LED modul	4000	24	3910	2150	1000	60	Detail
DEL69410	LED-1L16E700ZLEN83/PM23C/L100 3K#	IP40	LED modul	3000	34	5050	2780	1000	60	Detail
DEL69408	LED-1L16E500ZLEN83/PM23C/L100 3K#	IP40	LED modul	3000	24	3750	2060	1000	60	Detail
DEL69902	LED-1L16E700ZLEN83/PC23C/L100 4K#	IP40	LED modul	4000	34	5270	2900	1000	60	Detail
DEL69900	LED-1L16E500ZLEN83/PC23C/L100 4K#	IP40	LED modul	4000	24	3910	2150	1000	60	Detail
DEL69402	LED-1L16E700ZLEN83/PC23C/L100 3K#	IP40	LED modul	3000	34	5050	2780	1000	60	Detail
DEL69400	LED-1L16E500ZLEN83/PC23C/L100 3K#	IP40	LED modul	3000	24	3750	2060	1000	60	Detail
69408	LED-1L16C07ZLE11/PM23C/L100 3000#	IP40	LED modul	3000	27	3690	2030	1000	60	Detail
69410	LED-1L16B07ZLE11/PM23C/L100 3000#	IP40	LED modul	3000	33	4850	2670	1000	60	Detail
69908	LED-1L16C07ZLE11/PM23C/L100 4000#	IP40	LED modul	4000	27	3890	2140	1000	60	Detail
69910	LED-1L16B07ZLE11/PM23C/L100 4000#	IP40	LED modul	4000	33	5070	2790	1000	60	Detail
69400	LED-1L16C07ZLE11/PC23C/L100 3000#	IP40	LED modul	3000	27	3690	2030	1000	60	Detail
69402	LED-1L16B07ZLE11/PC23C/L100 3000#	IP40	LED modul	3000	33	4850	2670	1000	60	Detail
69900	LED-1L16C07ZLE11/PC23C/L100 4000#	IP40	LED modul	4000	27	3890	2140	1000	60	Detail
69902	LED-1L16B07ZLE11/PC23C/L100 4000#	IP40	LED modul	4000	33	5070	2790	1000	60	Detail

Code	Type	Ingress Protection	Socket	CCT (K)	Input [W]	Lum. flux of light source [lm]	Lum. flux of luminaire [lm]	Délka závěsu (mm)	Warranty (month)
DEL69911	LED-1L16E700ZLEN83/PM23C/L100 DALI 4K#	IP40	LED modul	4000	34	5270	2900	1000	60	Detail
DEL69909	LED-1L16E500ZLEN83/PM23C/L100 DALI 4K#	IP40	LED modul	4000	24	3910	2150	1000	60	Detail
DEL69411	LED-1L16E700ZLEN83/PM23C/L100 DALI 3K#	IP40	LED modul	3000	34	5050	2780	1000	60	Detail
DEL69409	LED-1L16E500ZLEN83/PM23C/L100 DALI 3K#	IP40	LED modul	3000	24	3750	2060	1000	60	Detail
DEL69903	LED-1L16E700ZLEN83/PC23C/L100 DALI 4K#	IP40	LED modul	4000	34	5270	2900	1000	60	Detail
DEL69901	LED-1L16E500ZLEN83/PC23C/L100 DALI 4K#	IP40	LED modul	4000	24	3910	2150	1000	60	Detail
DEL69403	LED-1L16E700ZLEN83/PC23C/L100 DALI 3K#	IP40	LED modul	3000	34	5050	2780	1000	60	Detail
DEL69401	LED-1L16E500ZLEN83/PC23C/L100 DALI 3K#	IP40	LED modul	3000	24	3750	2060	1000	60	Detail
69409	LED-1L16C07ZLE11/PM23C/L100 DALI 3000#	IP40	LED modul	3000	27	3690	2030	1000	60	Detail
69411	LED-1L16B07ZLE11/PM23C/L100 DALI 3000#	IP40	LED modul	3000	33	4850	2670	1000	60	Detail
69909	LED-1L16C07ZLE11/PM23C/L100 DALI 4000#	IP40	LED modul	4000	27	3890	2140	1000	60	Detail
69911	LED-1L16B07ZLE11/PM23C/L100 DALI 4000#	IP40	LED modul	4000	33	5070	2790	1000	60	Detail
69401	LED-1L16C07ZLE11/PC23C/L100 DALI 3000#	IP40	LED modul	3000	27	3690	2030	1000	60	Detail
69403	LED-1L16B07ZLE11/PC23C/L100 DALI 3000#	IP40	LED modul	3000	33	4850	2670	1000	60	Detail
69901	LED-1L16C07ZLE11/PC23C/L100 DALI 4000#	IP40	LED modul	4000	27	3890	2140	1000	60	Detail
69903	LED-1L16B07ZLE11/PC23C/L100 DALI 4000#	IP40	LED modul	4000	33	5070	2790	1000	60	Detail
